Size: 40x40x56mm (1.6x1.6x2.2inch)
Frame: Plastic UL94V0
Impeller: Plastic UL94V0
Lead Wire: UL1571AWG#28 or Equivalent (+) Red, (-) Black
Bearings: C=Ball Bearing
Life Expectancy: 70,000Hours at 20℃-Ball.
Temperature Range: Temperature Range
Operating: Temperature -10*C~70'C (Non-condensing)
Storage Temperature: -40'C~70'C (Non-condensing)
Approvals: CE, RoHS
DC FAN Specials: RD, FG, PWM
Rated Voltage: 12V Noise: 66.20~71.20dBA
Rated Current: 1.24~2.01A Rated Input Power: 14.88~24.12W
Speed: 17500~24000RPM Air Flow: 31.83~37.76CFM
Weight: 101.0g Mounting: Free Standing
| Model | Bearing System | Rated Voltage | Operating Voltage | Current | Input Power | Rated Speed | Air Flow | Air Pressure | Noise | Weight | |||
| Part No. | C | VDC | VDC | A | Watt | R.P.M | CFM | inch-H20 | mm-H20 | dBA | g | ||
| FD04056#12E | √ | 12 | 7.0~13.8 | 2.01 | 24.12 | 24000 | 21200 | 37.76 | 4.50 | 114.30 | 71.2 | 101.0 | |
| FD04056#12H | √ | 12 | 7.0~13.8 | 1.52 | 18.24 | 22100 | 19200 | 34.74 | 3.81 | 96.77 | 67.0 | 101.0 | |
| FD04056#12M | √ | 12 | 7.0~13.8 | 1.24 | 14.88 | 20200 | 17500 | 31.83 | 3.20 | 81.28 | 66.2 | 101.0 | |
| All models could be customized on voltage or any other requirements to fit your need. | |||||||||||||
