Size: 35x35x10mm (1.2x1.2x0.5inch)
Frame: Plastic UL94V0
Impeller: Plastic UL94V0
Lead Wire: UL1571AWG#28 or Equivalent (+) Red, (-) Black
Bearings: C=Ball Bearing&S=Sleeve Bearing
Life Expectancy: 70,000 Hours at 20℃-Ball. 30,000 Hours at 20℃-Sleeve
Temperature Range: Temperature Range
Operating Temperature: -10*C~70'C (Non-condensing)
Storage Temperature: -40'C~70'C (Non-condensing)
Approvals: UL, CUL, TUV, CE, RoHS
DC FAN Specials: RD, FG, IP54
Rated Voltage: 5V/12V Noise: 23.5~34.5dBA
Rated Current: 0.10~0.25A Rated Input Power: 0.60~2.16W
Speed: 6000~8000RPM Air Flow: 2.79~7.51CFM
Weight: 10g Mounting: Free Standing
| Model | Bearing System | Rated Voltage | Operating Voltage | Current | Input Power | Rated Speed | Air Flow | Air Pressure | Noise | Weight | |||
| Part No. | S | C | VDC | VDC | A | Watt | R.P.M | CFM | inch-H20 | mm-H20 | dBA | g | |
| FD03510#5H | √ | √ | 5 | 3.5~5.5 | 0.25 | 1.25 | 8000 | 6.20 | 0.15 | 3.81 | 29.8 | 10.0 | |
| FD03510#5M | √ | √ | 5 | 3.5~5.5 | 0.18 | 0.90 | 6000 | 4.46 | 0.08 | 2.03 | 23.5 | 10.0 | |
| FD03510#5L | √ | √ | 5 | 3.5~5.5 | 0.12 | 0.60 | 4000 | 2.79 | 0.04 | 1.02 | 21.0 | 10.0 | |
| FD03510#12H | √ | √ | 12 | 7.0~13.8 | 0.18 | 2.16 | 10000 | 7.51 | 0.21 | 5.33 | 34.5 | 10.0 | |
| FD03510#12M | √ | √ | 12 | 7.0~13.8 | 0.14 | 1.68 | 8000 | 6.20 | 0.15 | 3.81 | 29.8 | 10.0 | |
| FD03510#12L | √ | √ | 12 | 7.0~13.8 | 0.10 | 1.20 | 6000 | 4.46 | 0.08 | 2.03 | 23.5 | 10.0 | |
| All models could be customized on voltage or any other requirements to fit your need. | |||||||||||||
