Size: 80x80x38mm (3.2x3.2x1.5inch)
Frame: Plastic UL94V0
Impeller: Plastic UL94V0
Lead Wire: UL1007AWG#22 or Equivalent (+) Red, (-) Black
Bearings: C=Ball Bearing
Life Expectancy: 70,000 Hours at 40℃ Ball bearing
Input Voltage: A rated voltage range of 100V~240V (50/60Hz) AC&DC, Rotation speed remains constant even at different input voltages
Dielectric Strength: 1800VAC/SmA/3S (Between input terminal and frame)
Temperature Range: Operating Temperature -25*c~70'C (Non-condensing)
Storage Temperature: -40*C~80*C(Non-condensing)
EC FAN Specials: RD, FG, IP56
| Model | Bearing System | Rated Voltage | Power | Rated Speed | Air Flow | Air Pressure | Noise | Weight | ||
| Part No. | C | VDC | Watt | R.P.M | CFM | inch-H20 | mm-H20 | dBA | g | |
| EC08038##H | √ | 100~240 | 5.50 | 4000 | 42.26 | 0.32 | 8.13 | 38.9 | 162.0 | |
| EC08038##M | √ | 100~240 | 3.20 | 3500 | 36.69 | 0.25 | 6.35 | 35.1 | 162.0 | |
| EC08038##S | √ | 100~240 | 2.70 | 3000 | 31.20 | 0.18 | 4.57 | 30.1 | 162.0 | |
| All models could be customized on voltage or any other requirements to fit your need. | ||||||||||
