Size: 30x30x15mm (1.2x1.2x0.6inch)
Frame: Plastic UL94V0
Impeller: Plastic UL94V0
Lead Wire: UL1571AWG#28 or Equivalent (+) Red, (-) Black
Bearings: C=Ball Bearing&S=Sleeve Bearing
Life Expectancy: 70,000 Hours at 20℃-Ball. 30,000 Hours at 20℃-Sleeve
Temperature Range: Temperature Range
Operating Temperature: -10*C~70'C (Non-condensing)
Storage Temperature: -40'C~70'C (Non-condensing)
Approvals:UL, CUL, TUV, CE, RoHS
DC FAN Specials: RD, FG, IP54
Rated Voltage: 5V/12V Noise: 21.4~30.8dBA
Rated Current: 0.06~0.25A Rated Input Power: 0.72~1.25W
Speed: 6000~10000RPM Air Flow: 2.39~4.44CFM
Weight: 12g Mounting: Free Standing
| Model | Bearing System | Rated Voltage | Operating Voltage | Current | Input Power | Rated Speed | Air Flow | Air Pressure | Noise | Weight | |||
| Part No. | S | C | VDC | VDC | A | Watt | R.P.M | CFM | inch-H20 | mm-H20 | dBA | g | |
| FD03015#5H | √ | √ | 5 | 3.5~5.5 | 0.25 | 1.25 | 10000 | 4.44 | 0.25 | 6.35 | 30.8 | 12.0 | |
| FD03015#5M | √ | √ | 5 | 3.5~5.5 | 0.17 | 0.85 | 8000 | 3.39 | 0.15 | 3.81 | 26.2 | 12.0 | |
| FD03015#5L | √ | √ | 5 | 3.5~5.5 | 0.12 | 0.60 | 6000 | 2.39 | 0.08 | 2.03 | 21.4 | 12.0 | |
| FD03015#12H | √ | √ | 12 | 7.0~13.8 | 0.12 | 1.44 | 10000 | 4.44 | 0.25 | 6.35 | 30.8 | 12.0 | |
| FD03015#12M | √ | √ | 12 | 7.0~13.8 | 0.09 | 1.08 | 8000 | 3.39 | 0.15 | 3.81 | 26.2 | 12.0 | |
| FD03015#12L | √ | √ | 12 | 7.0~13.8 | 0.06 | 0.72 | 6000 | 2.39 | 0.08 | 2.03 | 21.4 | 12.0 | |
| All models could be customized on voltage or any other requirements to fit your need. | |||||||||||||
