Size: 80x80x25mm (3.2x3.2x1.0inch)
Frame: Plastic UL94V0
Impeller: Plastic UL94V0
Lead Wire: UL1007AWG#22 or Equivalent (+) Red, (-) Black
Bearings: C=Ball Bearing
Life Expectancy: 70,000 Hours at 40℃ Ball bearing
Input Voltage: A rated voltage range of 100V~240V (50/60Hz) AC&DC, Rotation speed remains constant even at different input voltages
Dielectric Strength: 1800VAC/SmA/3S (Between input terminal and frame)
Temperature Range: Operating Temperature -25*c~70'C (Non-condensing)
Storage Temperature: -40*C~80*C(Non-condensing)
EC FAN Specials: RD, FG, IP56
| Model | Bearing System | Rated Voltage | Power | Rated Speed | Air Flow | Air Pressure | Noise | Weight | ||
| Part No. | C | VDC | Watt | R.P.M | CFM | inch-H20 | mm-H20 | dBA | g | |
| EC08025##H | √ | 100~240 | 4.50 | 4000 | 43.54 | 0.34 | 8.64 | 38.1 | 95.0 | |
| EC08025##M | √ | 100~240 | 2.80 | 3500 | 37.76 | 0.26 | 6.60 | 33.6 | 95.0 | |
| EC08025##S | √ | 100~240 | 1.60 | 3000 | 31.84 | 0.19 | 4.83 | 29.1 | 95.0 | |
| All models could be customized on voltage or any other requirements to fit your need. | ||||||||||
